Family Basket Swing : FBS

Description

Our Family Basket Swing is at the top end of our range of swing sets. It has the capacity to take the weight of several people at once making it a unique piece of equipment that adults can use to relax in when the children are not using it.

It is extremely robust using larger poles than our standard swing frames in order to support the heavy basket. The swing is therefore suitable for groups of children as well as adults to use.

This product comes with a black basket as standard. Please call the office on 01577 840570 or email us on info@caledoniaplay.com to order a red and blue basket.

Our Family Basket Swing has been designed to be freestanding and does not need to be concreted in or anchored down however it can be secured to the ground with optional ground anchors if required for additional security.

We recommend the use of grass safety mats under the swing to reduce ground erosion.

The 1.2m diameter basket has an internal galvanised steel ring, 16mm herculean rope and conforms to European Safety Standard EN1176.

The space required for the large footprint of the Family Basket Swing and to allow swinging is 4.0 x 6.0m. The capacity is approximately 1000kg.

All timbers are supplied from PEFC registered forests pressure treated with non-arsenic preservative and impregnated with wax

The Family Basket Swing is particularly popular with children and young adults with special educational needs and disabilities (SEND).

Specification

The 1.2m diameter basket has an internal galvanised steel ring, 16mm herculean rope and conforms to safety standard EN1176

10cm Machine rounded timber legs support a 14cm diameter top swing pole

Timber legs are held into position with 3.0m x 10cm half round stretchers

Universal joint stainless steel casting swing pivot points, secured by M16 threaded bar and fitted with mounting cap bolt

Frame structure is strengthened with 4 diagonal bracers, each secured with 4 x M8 bolts

Basket height from ground 400mm

All the timbers have been pressure treated and impregnated with wax, providing a more repellent surface so reducing water absorption and delaying future rotting of the timber.

Dimensions

Length 3.0m

Width 3.3m

Height 2.4m

Area required 6.0 x 7.3m (calculated by adding 1.5 around the product and 2.0 in front or behind the swing)
